[VehicleTechnical Parameters] | |
Product Name | Jiefang 9 cubic compressed garbage truck |
Curb weight (kg) | 9100 |
Total size (mm) | 7340x2350x2800(mm) |
Box volume (m3) | 9 |
Box thickness (mm) | Side plate 4/bottom 5 |
Box material quality | T355Manganese steel |
Compression density (t/m & sup3;) | 0.6-0.8 |
Working ambient temperature (℃) | -20-45 |
Sewage tank capacity (liters) | 850 |
Filling cycle time (S) | ≤35 |
Compression cycle time (S) | ≤15 |
Uninstall cycle time (S) | ≤60 |
Operation mode | 3 |
Maximum personnel allowed to enter the cab | Automatic/remote control |
Maximum speed (km/h) | 100 |
[Chassis Technical Parameters] | |
Chassis brand | FAW |
Brake | AIR brake |
Fuel type | diesel fuel |
Engine power (kilowatts) | 117 |
Front axle/rear axle (t) | 4.5/8 |
Transmission model | 8 |
Number of axes | 2 |
Wheelbase (mm) | 4700 |
Number of tires | 6 |
Tire size | 9.00R20 |
