[VehicleTechnical Parameters] | |
Product Name | compressed rubbish vehicle |
Kerb Weight (Kg) | 6495 |
Overall Dimensions (mm) | 6800*2550*2950 |
Box volume (m3) | 10 |
Box thickness (mm) | 4 on the side and 4 at the bottom |
Box Body Material Quality | Q345 manganese steel plate |
Compression Density (t/m ³） | 0.6-0.8 |
Working ambient temperature (℃) | -20~45 |
Sewage Tank Capacity (L) | 600 |
Filling cycle time (S) | ≤35 |
Compression cycle time (S) | ≤15 |
Uninstall cycle time (S) | ≤60 |
Operating Mode | Automatic + Manual |
Max Passengers Allowed | 3 |
[Chassis Technical Parameters] | |
Brand Name | 1-FAW |
Brake | Empty ship air brake/oil brake |
Fuel type | diesel |
Engine Power（kw） | 110 |
Front Axle/Rear Axle (t) | 4.5/9 |
Gearbox Model | 8-speed transmission |
Number of axes | 2 |
Wheelbase (mm) | 3800 |
Number of tires | 6 |
Tire size | 9.00R20 |
