[VehicleTechnical Parameters] | |
Product Name | compression garbage truck |
Kerb Weight (Kg) | 10980 |
Overall Dimensions (mm) | 9000*2550*3350 |
Box volume (m3) | 12 |
Box thickness (mm) | 4 on the side and 5 at the bottom |
Box Body Material Quality | Q345 manganese steel plate |
Compression Density (t/m ³） | 0.6-0.8 |
Working ambient temperature (℃) | -20~45 |
Sewage Tank Capacity (L) | 600 |
Filling cycle time (S) | ≤35 |
Compression cycle time (S) | ≤15 |
Uninstall cycle time (S) | ≤60 |
Operating Mode | Automatic + Manual |
Max Passengers Allowed | 3 |
[Chassis Technical Parameters] | |
Brand Name | SHACMAN |
Brake | Air brake/oil brake |
Fuel type | Diesel |
Engine Power（kw） | 180 |
Front Axle/Rear Axle (t) | 5/10 |
Gearbox Model | 8-speed manual |
Number of axes | 4*2 |
Wheelbase (mm) | 4500 |
Number of tires | 6 |
Tire size | 10.00R20 18PR |
