CHU SHENG
Crane truck, the full name is truck-mounted lifting transport vehicle.
In some places Also known as car crane, self-crane and so on. It is a kind of equipment that integrates hoisting and transportation, and realizes the lifting, turning, and hoisting of goods through hydraulic lifting and telescopic systems.
4.New type cab, adjustable suspension seat, air motive shed, electron-hydraulic proportional handle and the push-button control,large color display and new dashboard, electric control outrigger, electric control engine, electric control hydraulic torque converter gearbox, brake steering drive axle, easy and safe to operate.
| Product name | FAW 4X2 8 Ton Hydraulic Folding Arm Crane Truck Mounted Crane | 125km/h | Crane | 8 ton knuckle boom crane | ||
| Chassis Brand | FAW | Axles | 4 | Arms sections | 3 | |
| Rated loading weight | 12000KG | Engine Brand | weichai | Max lifting capacity | 8 ton | |
| Curb weight | 6000KG | Horse Power | 210hp | Max lifting height | 12 m | |
| Dimensions | 9000x2550x3650mm | Emissions | 8600Lml | Max working radius | 9.7 m | |
| Cargo body dimension | 5700x2460x600mm | Cab | one and half row | Operation pressure | 25 mpa | |
| Wheelbase | 2100+4575+1400mm | Tire | 6 | Deadweight of crane | 3.2 ton | |
| Drive type | 4X2 | Gross weight | 7000kg | Rotation angle | 360 full rotation | |
![[pics:title]](/static/upload/image/20251009/1760014294152222.jpg)
![[pics:title]](/static/upload/image/20251009/1760014295971355.jpg)
![[pics:title]](/static/upload/image/20251009/1760014295111741.jpg)
![[pics:title]](/static/upload/image/20251009/1760014295786331.jpg)
