engine

Yunnei 4102QBZL , 115 horsepower engine Air brake 5-speed gearbox 7.00 steel wire tire

wheelbase (  mm)

3300mm

driver's cab

Can carry 2 people

Maximum gross mass (kg) )

4500

Maximum working height

12M

External dimensions (length × width) (×high)

5900×2080×2450 (mm) )

Curb weight (kg) )

Rated load of the work platform (kg)

200

Work platform

High-strength stainless steel dimensions: 1600X700X1000 (mm) Insulated suspended platform optional.

Rotary device

360-degree continuous rotation

Maximum operating range

5M

Working radius at maximum working height

5M

Maximum working radius and working height

5M

outrigger stride

4600/4400mm

Maximum driving speed

110km/h

boom type

Three-section heptagonal working arm Synchronous scaling

control system

The CAN bus control system is equipped with a wireless remote control and enables stepless speed regulation.

outrigger

V-shaped front and H-shaped rear Individually adjustable (control) )

operate

Electrical control operation Also equipped with manual emergency operation

Leveling system

Static liquid automatic leveling

Power Take-Off System

Mechanical operation
