[Vehicle Technical Parameters] | |
Product Name | Water tank truck/water truck/drink truck |
Volume (L) | 15000 |
Border dimensions (mm) | 8420*2500*2980 |
Tank thickness (mm) | 5 |
Tank material | Q235 carbon steel |
Pump model | 60/90 |
Pump flow rate (m & sup3;/h) | 60 |
Water absorption depth (meters) | 7 |
Front spray width (meters) | 5.5 |
Rear nozzle width (meters) | 11 |
Tail flush width (meters) | 18 |
Water cannon range (meter) | 30-35 |
Truck paint | Sandblasting/rust-proof treatment |
Outlet ball valve | 50* stainless steel ball valve |
connect | Bolt connection |
【Chassis Technical Parameters] | |
Chassis brand | DF |
Brake | Air brake |
Fuel type | diesel fuel |
Engine power (kilowatts) | 155 |
Front axle/rear axle (t) | 5/10 |
Transmission | 8-speed gearbox |
Number of Axles | 2 |
Wheelbase (mm) | 4500 |
Number of tires | 6 |
Tire specifications | 10.00R20 |
