CHU SHENG
[Vehicle Technical Parameters] | |
Product Name | Water tank truck/water truck/beverage truck |
Tank Volume(m³) | 20000 |
Border dimensions (mm) | 12000*2550*3500 |
Tank thickness (mm) | 5 |
Tank Body Material | Q235 carbon steel /304 stainless steel |
Pump model | 50/110 |
Pump flow rate (m & sup3;/h) | 50 |
Water absorption depth (meters) | 7 |
Front spray width (meters) | 5.5 |
Rear nozzle width (meters) | 11 |
Tail flush width (meters) | 18 |
Water cannon range (meter) | 30-35 |
Truck paint | Sandblasting/anti-rust treatment |
Outlet ball valve | 50* stainless steel ball valve |
connect | bolted connection |
【Chassis Technical Parameters] | |
Chassis Brand | HOWO |
Brake | air brake |
Type of fuel | diesel |
Engine power (KW) | 235 |
Front axle/rear axle (t) | 5.5/13 |
Gearbox | 12-speed gearbox |
Number of Axles | 6*4 |
Wheelbase (mm) | 4250+1350 |
Number of tires | 10 |
Tire specifications | 12.00R20 |
