【Vehicle Technical Parameters】 | ||
Product Name | Sewage Cleaning Truck | |
Kerb weight (Kg) | 25000 | |
Overall Dimensions (mm) | 11200×2540×3600 | |
Box Volume (m3) | 30 | |
Box Thickness (mm) | 8 | |
Box Body Material Quality | Q345 Manganese Steel | |
Working Environment Temperature (℃) | -20~45 | |
Sewage Tank Capacity (L) | 1400 | |
Sewage pump | Vacuum Pump | |
Speed (r.p.m.) | 590 | |
Pressure (Mpa) | 0-1 | |
Water consumption (L /min)i/min | 140~180 | |
Operating Mode | Automatic+Manual | |
High pressure pump flow(L /min) | 54 | |
Stress( Mpa) | 8 | |
Cab Capacity | 3 Persons Allowed | |
【Chassis Technical Parameters】 | ||
Chassis Brand | FAW | |
Brake | Air Brake/Oil Brake | |
Type of fuel | Diesel | |
Engine Power（KW） | 239 | |
Front Axle/Rear Axle（t） | 10/20 | |
Gearbox | 12-Speed Manual | |
Number of Axes | 3 | |
Wheelbase (mm) | 1950+4550+1350 | |
Number of Tires | 12 | |
Tire Specification | 11.00R20 20PR | |
