CHU SHENG
[Overall Technical Parameters ] | ||
Product Name | Cement Concrete Mixer Truck | |
Kerb weight (Kg) | 24500 | |
Overall Dimensions (mm) | 9875×2550×3965 | |
Box Volume (m3) | 5 | |
Box Thickness (mm) | 5 | |
Box Body Material Quality | Q345 Manganese Steel | |
Working Environment Temperature (℃) | -20~45 | |
Reduction Gear | Horizontal gear reduction motor（1:3-1:200） | |
Water Pump | 30MPa | |
Radiator | 1-suzu 51Y | |
Operating Mode | Automatic+Manual | |
[Chassis Technical Parameters] | ||
Chassic Brand | Howo | |
Brake | Air Brake/Oil Brake | |
Fuel Type | Diesel | |
Engine Power（kw） | 257 | |
Front Axle/Rear Axle (t) | 5/11.5 | |
Gearbox Model | 8-Speed Manual | |
Number of Axles | 3 | |
Wheelbase (mm) | 3225+1350 | |
Number of Tires | 10 | |
Tire Size | 11.00R20 | |
![[pics:title]](/static/upload/image/20251023/1761185229633014.jpg)
![[pics:title]](/static/upload/image/20251023/1761185230220830.jpg)
![[pics:title]](/static/upload/image/20251023/1761185230142978.jpg)
![[pics:title]](/static/upload/image/20251023/1761185230783046.jpg)
