CHU SHENG
[Overall Technical Parameters ] | ||
Product Name | Cement Concrete Mixer Truck | |
Kerb weight (Kg) | 31000 | |
Overall Dimensions (mm) | 9990×2550×3995 | |
Box Volume (m3) | 8 | |
Box Thickness (mm) | 5 | |
Box Body Material Quality | Q345 Manganese Steel | |
Working Environment Temperature (℃) | -20~45 | |
Reduction Gear | Horizontal gear reduction motor（1:3-1:200） | |
Water Pump | 30MPa | |
Radiator | 1-suzu 51Y | |
Operating Mode | Automatic+Manual | |
[Chassis Technical Parameters] | ||
Chassic Brand | Howo | |
Brake | Air Brake/Oil Brake | |
Fuel Type | Diesel | |
Engine Power（kw） | 257 | |
Front Axle/Rear Axle (t) | 11/15 | |
Gearbox Model | 12-Speed Manual | |
Number of Axles | 4 | |
Wheelbase (mm) | 1800+3050+1400 | |
Number of Tires | 12 | |
Tire Size | 11.00R20 18PR | |
![[pics:title]](/static/upload/image/20251023/1761185727873761.jpg)
![[pics:title]](/static/upload/image/20251023/1761185728860842.jpg)
![[pics:title]](/static/upload/image/20251023/1761185728478132.jpg)
![[pics:title]](/static/upload/image/20251023/1761185729331529.jpg)
