Mixer Truck Price Advantage Bulk Order Support for Overseas Traders and Contractors

Chassis parameters
Chassis model		DYQ1161D5AA	Chassis brand	DAYUN TRUCK
Overall dimensions		6240x2370x3050mm	Wheel base	3600mm
Front/rear wheel track		1940/1860mm	Front/rear suspension	1240/1400mm
Approach/departure angle		25/29°	Maximum speed	90km/h
Chassis Manufacturer		DAYUN AUTOMIBILE CO.,LTD
Cab	Configuration	allowable 3 passengers
	Color	white,other color is optional
Engine	Model	YC4S140-50
	Emission	Euro 5
	Type	4 cylinders,in-line,water-cooled, turbo inter-cooling, diesel engine
	Rated power	140hp
	Displacement	3767ml
	Bore x stroke	102×115mm
	Manufacturer	Guangxi Yuchai Machinery Group Co.,Ltd
Tire	Size	9.00-20 nylon tire
	Number	6+1 nos
Brake	Air brake
Fuel tank	120L
Rear axle	10T rear axle
Drive form	4X2
Rated voltage	24V, DC
Transmissions	6 speed forward 1 reverse
Steering device	Power assisted steering
Steering wheel	Left hand drive
Selective configuration
If there is a slight change in the chassis parameters above,please take the actual product as the standard

Concrete mixer truck structure parameters
Mixing capacity(m³)	5	Color and Logo	Optional
Feeding speed (m³/min)	≥3	Discharge speed(m³/min)	≥2
Discharge residual rate	≤0.5%	Slump scope(mm)	50-210
Water tank capacity(L)	300	Water pressure(Mpa)	0.35-0.38
Tank material	5mm alloy steel	Tank front head	6mm alloy steel
Reducer	Keyi	Hydraulic motor	DALI
Hydraulic pump	Changyuan	Radiator	ZHENGHUA
Standard configuration	Less than 7m3:chassis,sub frame,mixer tank(main tank 5mm alloy steel wear resistant material,front tank head 6mm alloy steel wear resistant material),domestic reducer,hydraulic pump,hydraulic motor,radiator,water tank,cleaning hose,feed port, discharge port,climbing ladder,air pressure water supply device.
Selective configuration	1,American SALI56 hydraulicy pump, SALI63 hydraulic motor 2,Italy P071 hydraulic pump, M063 hydraulic motor 3,A full set of imported parts (ZF3301 reducer)
