CHU SHENG
Vehicle Parameters | |||
Vehicle Model | EHY5255GJBSX | Vehicle Brand | HUAYI |
Overall dimensions | 9750X2600X4000mm | Curb weight | 11500kg |
Loading capacity | 10m3 | Color | optional |
Chassis Parameters | |||
Chassis model | SX5255GJBJR404 | Chassis brand | SHACMAN |
Overall dimensions | 9000x2495x3250mm | Wheel base | 3975+1400mm |
Front/rear wheel track | 2015,1850/1850mm | Front/rear suspension | 1430/1000mm |
Approach/departure angle | 19/24° | Maximum speed | 82km/h |
Cab | Configuration | Delong F3000 flat top cab, hydraulic seat, four-point hydraulic suspension cab, air conditioning, electric window machine, manual flip, F3000 Cooling System, Domestic Left-hand Steering Machine, Iron Storage Tank, Foyer Air Filter, Iron Bumper, 165Ah Battery, ETA Circuit Breaker, SHACMAN logo, all English identification. | |
Color | White, other color is optional | ||
Engine | Model | WP10.340E22 | |
Emission | Euro 2 | ||
Type | 6 cylinders, in-line, diesel engine. | ||
Rated power | 340hp,rated power speed 2200rpm | ||
Displacement | 9726CC | ||
Max.torque | 1250N.m | ||
Bore x stroke | 126X155mm | ||
Manufacturer | Weichai Power CO.,LTD | ||
Tire | 12.00R20 steel wire tire 10+1 nos | Transmission | 10 speed forward 2 reverse |
Steering device | Power assisted steering | Steering wheel | Left hand drive |
Concrete Mixer Structure Parameters | |||
Mixing capacity(m³) | 10 | Color and Logo | Optional |
Tank material | 4mm alloy steel | Tank front head | 8mm alloy steel |
Hydraulic pump | ITALY ARK | Hydraulic motor | ITALY ARK |
Radiator | KAIPENG | Color and Logo | Optional |
Standard Configuration | chassis,sub frame,mixer tank, ITALY TOPUNION reducer, ITALY ARK hydraulic pump and hydraulic motor, radiator,water tank,cleaning hose,feed port, discharge port,climbing ladder,air pressure water supply device. | ||
