Vehicle Technical Parameters | ||
Product Name | Dump Truck | |
Overall Dimensions(mm) | 8585x2550x3650 | |
Curb Weight(Kg) | 12500 | |
Loading Capacity(Kg) | 12370 | |
Total Mass(Kg) | 25000 | |
Cargo Tank Dimension（mm） | 5600x2350x1500 | |
Cargo Tank Volume(m³) | 20 | |
Tank Body Material | carbon Steel | |
Cargo Tank thickness（mm） | Side 6 Bottom 8 | |
Cargo Tank Lifting Method | Hydraulic Cylinder Lifting | |
Number of Cylinders（pcs） | 1 | |
Cylinder Position | Girder Front/Middle | |
Cylinder Diameter（mm） | 180 | |
Door Position | Rear/Side/Top | |
Chassis Technical Parameters | ||
Chassis Brand | 1SUZU | |
Drive Form | 6*4 | |
Steering Wheel | Left Hand Drive | |
Steering Device | Power Assisted Steering | |
Wheelbase(mm) | 4100+1350 | |
Engine Brand and Model | Weichai Power/WP12.400E50 | |
Max Engine Power(Kw) | 294 | |
Engine Displacement(ml) | 11600 | |
Engine Emission Standard | Euro 6 | |
Number of Engine Cylinders | 6 | |
Fuel Type | Diesel | |
Gearbox | 12 Speed Forward 1 Reverse | |
Front/Rear Axle(t) | 7/7/18 | |
Suspension | Multi Leaf Springs | |
Brake System | Front/Rear Drum Full Air Braking | |
Wheels and Tyre Size | 12+1/( 12.00R20LT) | |
Cab Configuration | Single Row Cab, Air Conditioning, Radio, MP3 and USB Port | |
Rated Voltage | 24V,DC | |
Cab Color | White,other color is optional | |
