Vehicle Technical Parameters | ||
Product Name | Dump Truck | |
Kerb Weight (Kg) | 3390 | |
Overall Dimensions(mm) | 5260×2020×2680 | |
Total Mass(Kg) | 4495 | |
Cargo Tank Volume(m³) | 3.0 | |
Cargo Tank Dimension（mm） | 2400×2100×600 | |
Tank Body Material | Q235 Carbon Steel | |
Cargo Tank Thickness（mm） | Side 3 Bottom 4 | |
Cargo Tank Lifting Method | Hydraulic cylinder lifting | |
Number of Cylinders（pcs） | 1 | |
Cylinder Position | Girder front | |
Cylinder Diameter（mm） | 100 | |
Door Position | Rear/Side/Top | |
Chassis Technical Parameters | ||
Chassis Brand | JMC | |
Brake | Air Brake/Oil Brake | |
Fuel Type | Diesel | |
Engine Power（kw） | 67 | |
Front Axle/Rear Axle (t) | 2/3.5 | |
Gearbox Model | 6-Speed Manual | |
Number of Axles | 2 | |
Wheelbase (mm) | 2800 | |
Number of Tires | 6 | |
Tire Size | 6.50R16 | |
