Oil transportation vehicle
[Vehicle Technical Parameters] | |
Product Name | Fuel Tanker Truck |
Curb Weight(Kg) | 3800 |
Boundary Dimension(mm) | 5995*2100*2700 |
Tank Volume(m³) | 5 |
Tank Thickness（mm） | 5 |
Tank Body Material | 304 Stainless Steel/Q235 Carbon Steel |
Anti Wave Plate | yes |
Operating Ambient Temperature（°C） | -20~45 |
Manhole Cover | European standard |
Emergency Shut Off Valve | yes |
Oil Gas Recovery Unit | yes |
Anti-Overflow Alarm Device | yes |
Fuel Loading method | Bottom filling |
Gear Oil Pump Flow(m³/h) | 60 |
Toolbox | Customized to your needs |
Maximum Speed（km/h） | 80 |
[Chassis Technical Parameters] | |
Chassis Brand | FAW |
Type of Fuel | Diesel Oil |
Engine Power（KW） | Yuchai 95KW |
Front Wheel Braking | Disc brake |
Front Axle/Rear Axle（t） | 3.5/7.5 |
Gearbox | 5 Speed Manual |
Brake | Air brake |
Front Wheel Braking | Disc brake |
Number of Axles | 2 |
Wheelbase (mm) | 3845 |
Number of Tires | 6 |
Tyre Specification | 7.00R16LT 14PR |
![[pics:title]](/static/upload/image/20251011/1760160709938545.jpg)
![[pics:title]](/static/upload/image/20251011/1760160708262202.jpg)
![[pics:title]](/static/upload/image/20251011/1760160708144110.jpg)
![[pics:title]](/static/upload/image/20251011/1760160708419983.jpg)
