CHU SHENG
[Technical Parameters of the Entire Vehicle] | |
Kerb Weight (Kg) | 18600 |
Overall Dimensions(mm) | 10000*2500*3600 |
Box Volume(m³) | 43 |
Box Size(mm) | 7200*2440*2500 |
Refrigeration Temperature Range(℃) | -18 |
Condenser Size(mm) | 580×1310×380 |
Evaporator Size(mm) | 580×1310×380 |
Material of the Insulation Layer of the Box | Polyurethane Foam |
Insulation Thickness(mm) | 80 |
[Chassis Technical Parameters] | |
Trade Name | Isuzu |
Brake | Automatically Air-cut Brake |
Type of Fuel | Diesel |
Front Axle/Rear Axle(t) | 5/10 |
Engine Power(kw) | 260 |
Gearbox | 8-Speed Transmission |
Number of Axles | 3 |
Wheelbase (mm) | 4350+1350 |
Tire Size | 275/80R22.5 |
