CHU SHENG
[Technical Parameters of the Entire Vehicle] | |
Kerb Weight (Kg) | 8100 |
Overall Dimensions(mm) | 9200×2600×3900 |
Box Volume(m³) | 40 |
Box Size(mm) | 6800*2400*2500(mm) |
Refrigeration Temperature Range(℃) | -5~-18 |
Refrigeration Capacity (w) | 11600 |
Condenser Size(mm) | 350×2020×340 |
Evaporator Size(mm) | 680×1780×380 |
Material of the Insulation Layer of the Box | Polyurethane Foam |
Insulation Thickness(mm) | 80 |
Chassis Technical Parameters] | |
Trade Name | Isuzu |
Brake | Air Brake/Oil Brake |
Type of Fuel | Diesel |
Front Axle/Rear Axle(t) | 5/10 |
Engine Power(kw) | 176 |
Gearbox | 8-Speed Transmission |
Number of Axles | 2 |
Wheelbase (mm) | 5000 |
Tire Size | 10.00R20 |
