CHU SHENG
[Technical Parameters of the Entire Vehicle] | |
Kerb Weight (Kg) | Refrigerated Truck |
Overall Dimensions(mm) | 9200*2600*3500 |
Box Volume(m³) | 41 |
Box Size(mm) | 6800*2500*2400 |
Refrigeration Temperature Range(℃) | -5°/-18° |
Refrigeration Capacity (w) | 8800 |
Condenser Size(mm) | 580×1310×380 |
Evaporator Size(mm) | 580×1310×380 |
Material of the Insulation Layer of the Box | Polyurethane Foam |
Insulation Thickness(mm) | 80 |
Chassis Technical Parameters] | |
Trade Name | Fotou |
Brake | automatically air-cut brake |
Type of Fuel | diesel |
Front Axle/Rear Axle(t) | 5/10 |
Engine Power(kw) | 165 |
Gearbox | 8-Speed Transmission |
Number of Axles | 2 |
Wheelbase (mm) | 5100 |
Tire Size | 10.00R20 |
