CHU SHENG
[Technical Parameters of the Entire Vehicle] | |
Kerb Weight (Kg) | 4495 |
Overall Dimensions(mm) | 5995*2260*3230mm |
Box Volume(m³) | 18 |
Box Size(mm) | 4080*2100*2100 |
Refrigeration Temperature Range(℃) | -5~-15 |
Refrigeration Capacity (w) | 6860 |
Condenser Size(mm) | 980×1310×380 |
Evaporator Size(mm) | 780×1220×330 |
Material of the Insulation Layer of the Box | Polyurethane Foam |
Insulation Thickness(mm) | 80 |
Chassis Technical Parameters] | |
Trade Name | 1suzu |
Brake | Air Brake |
Type of Fuel | Diesel |
Front Axle/Rear Axle(t) | 3/6 |
Engine Power(kw) | 97 |
Gearbox | 5-Speed Transmission |
Number of Axles | 2 |
Wheelbase (mm) | 3360 |
Tire Size | 750R16 |
![[pics:title]](/static/upload/image/20251012/1760280799811179.jpg)
![[pics:title]](/static/upload/image/20251012/1760280794559008.jpg)
![[pics:title]](/static/upload/image/20251012/1760280800242818.jpg)
![[pics:title]](/static/upload/image/20251012/1760280802829983.jpg)
