CHU SHENG
[Technical Parameters of the Entire Vehicle] | |
Kerb Weight (Kg) | Refrigerated Truck |
Overall Dimensions(mm) | 9400*2550*3850 |
Box Volume(m³) | 42 |
Box Size(mm) | 6800*2450*2500 |
Refrigeration Temperature Range(℃) | -18°~+20° |
Refrigeration Capacity (w) | 8800 |
Condenser Size(mm) | 580×1310×380 |
Evaporator Size(mm) | 580×1310×380 |
Material of the Insulation Layer of the Box | Polyurethane Foam |
Insulation Thickness(mm) | 80 |
Chassis Technical Parameters] | |
Trade Name | Foton |
Brake | automatically air-cut brake |
Type of Fuel | Pure electricity |
Front Axle/Rear Axle(t) | 5/10 |
Engine Power(kw) | 349 |
Gearbox | Automatic Gear |
Number of Axles | 2 |
Wheelbase (mm) | 5150 |
Tire Size | 11R22.5 18PR |
![[pics:title]](/static/upload/image/20251012/1760281246361353.jpg)
![[pics:title]](/static/upload/image/20251012/1760281245271225.jpg)
![[pics:title]](/static/upload/image/20251012/1760281246896319.jpg)
![[pics:title]](/static/upload/image/20251012/1760281245331376.jpg)
