【Vehicle Technical Parameters】 | |
Product Name | Wrecker Towing Truck |
Curb Weight(Kg) | 4495(Kg) |
Boundary Dimension(mm) | 5995×2550,2500,2450,2400,2350,2300×2300,2250(mm) |
Slab Length(mm) | 4200+1200 |
Plate Width（mm） | 2450 |
Plate Bearing Weight（t） | 5ton |
The Rear Bracket Arm Carries The Weight(t) | 3ton |
Winch Pull（t） | 4ton |
Total Length of Wire Rope（m） | 21 |
Auxiliary Wheel | 2 |
Max Passengers Allowed | 2/3 |
【Chassis Technical Parameters】 | |
Chassis Name | JAC |
Brake | air Brake |
Type of Fuel | Pure electric |
Engine Power（KW） | 130 |
Front Axle/Rear Axle（t） | 3/5 |
Gearbox | Automatic transmission |
Number of Axles | 2 |
Wheelbase (mm) | 3600 |
Number of Tires | 6 |
Tire Spec. | 7.00r16 |
![[pics:title]](/static/upload/image/20251012/1760282411128122.png)
![[pics:title]](/static/upload/image/20251012/1760282405693066.png)
![[pics:title]](/static/upload/image/20251012/1760282411408923.png)
![[pics:title]](/static/upload/image/20251012/1760282411660459.png)
