CHU SHENG
【Vehicle Technical Parameters】 | |
Product Name | Shaanxi Automobile Wrecker |
Curb Weight(Kg) | 18000 |
Boundary Dimension(mm) | 9000*2550*3200 |
Slab Length(mm) | 7800 |
Plate Width（mm） | 2550 |
Plate Bearing Weight（t） | 10 |
8The Rear Bracket Arm Carries The Weight(t） | 8 |
Winch Pull（t） | 10 |
Total Length of Wire Rope（m） | 30 |
Auxiliary Wheel | A Pair |
Operating Ambient Temperature（°C） | -20~45 |
Max Passengers Allowed | 3 |
【Chassis Technical Parameters】 | |
Chassis Name | shacman |
Brake | Automatically Air-Cut Brake |
Type of Fuel | Diesel Oil |
Engine Power（KW） | 169 |
Front Axle/Rear Axle（t） | 6/10 |
Gearbox | 8 Speed Manual Transmission |
Number of Axles | 2 |
Wheelbase (mm) | 5000 |
Number of Tires | 6 |
Tire Size | 10.00R20 |
