【Vehicle Technical Parameters】 | |
Product Name | Wrecker Towing Truck |
Curb Weight(Kg) | 31000 |
Boundary Dimension(mm) | 11500*2550*3980 |
Plate Width（mm） | 2550 |
Plate Bearing Weight（t） | 20 |
The Rear Bracket Arm Carries The Weight(t） | 35 |
Winch Pull（t） | 20 |
Total Length of Wire Rope（m） | 20 |
Auxiliary Wheel | A Pair |
Operating Ambient Temperature（°C） | -20~45 |
Max Passengers Allowed | 2 |
【Chassis Technical Parameters】 | |
Chassis Name | ISUZU |
Brake | Automatically Air-Cut Brake |
Type of Fuel | Diesel Oil |
Engine Power（KW） | 327KW |
Front Axle/Rear Axle（t） | 7/18 |
Gearbox | 10Speed Manual Transmission |
Number of Axles | 4 |
Wheelbase (mm) | 1950+4600+1400 |
Number of Tires | 12 |
Tire Size | 12.00R20 |
