【Vehicle Technical Parameters】 | ||
Product Name | Wrecker Towing Truck | |
Curb Weight(Kg) | 13300 | |
Boundary Dimension(mm) | 8070×2550×3700 | |
Slab Length(mm) | 5200 | |
Plate Width（mm） | 2550 | |
Plate Bearing Weight（t） | 8 | |
The Rear Bracket Arm Carries The Weight(t) | 8 | |
Winch Pull（t） | 6.38 | |
Total Length of Wire Rope（m） | 8 | |
Auxiliary Wheel | 30 | |
Operating Ambient Temperature（°C） | -20~45 | |
Max Passengers Allowed | 3 | |
【Chassis Technical Parameters】 | ||
Chassis Name | Howo | |
Brake | Automatically Air-Cut Brake | |
Type of Fuel | Diesel Oil | |
Engine Power（KW） | Wei Chai 220 | |
Front Axle/Rear Axle（t） | 6/10 | |
Gearbox | 8 Speed Manual Transmission | |
Number of Axes | 2 | |
Wheelbase (mm) | 5000 | |
Number of Tires | 6 | |
Tire Spec. | 10.00R20 | |
