Vehicle Technical Parameters | ||
Product Name | Wrecker Towing Truck | |
Curb Weight(Kg) | 22190 | |
Overall Dimension(mm) | 10650×2520×3200 | |
Maximum Towing and Traction Mass（kg） | 34000 | |
Max. Lifting Capacity（kg | 20000 | |
Max. Lifting Height（m） | 5.4 | |
Max. Towing Capacity（kg） | 18000 | |
Maximum Towing Capacity at Full Extension (kg) | 9000 | |
Winch Pulling Capacity(Kg) | 20000 | |
Steel Wire Rope(m) | 45 | |
Toolbox Materials | Carbon Steel /Aluminum Alloy Optional | |
Fixing Fork(pcs) | 5 | |
L-shaped Tire Holder(pair) | 1 | |
Chain Hook（pcs） | 1 | |
Yellow Warning Lights Optional（pcs） | 1 | |
Auxiliary Tracheal Assembly（pcs） | 1 | |
Binding Straps（pcs） | 2 | |
Chassis Technical Parameters | ||
Chassis Brand | Sinotruk Howo | |
Drive Form | 6*4 | |
Type of Fuel | Diesel Oil | |
Engine Power（KW） | 280 | |
Front Axle/Rear Axle（t） | 7/9/9 | |
Gearbox | 10JSD180+QH50,10 speed forward 2 reverse | |
Number of Axles | 3 | |
Wheelbase (mm) | 5600+1350 | |
Number of Tires | 6 | |
Tyre Specification | ( 12.00R20) | |
![[pics:title]](/static/upload/image/20251024/1761279003119570.jpg)
![[pics:title]](/static/upload/image/20251024/1761279003201515.jpg)
![[pics:title]](/static/upload/image/20251024/1761279003717284.jpg)
![[pics:title]](/static/upload/image/20251024/1761279003895503.jpg)
