CHU SHENG
Vehicle Parameters | |||
Vehicle model | EHY5040CLC | Vehicle brand | HUAYI |
Vehicle dimension | 5995X2070X2650mm | Curb weight | 4400kg |
Loading Capacity | 4m3 | ||
Chassis Parameters | |||
Chassis model | KMC104033D9 | Chassis brand | KAMA |
Overall dimensions | 5939x1940x2120mm | Wheel base | 3300mm |
Cab | Single row cab,allowable 3 passengers | ||
Engine | XICHAI 4DW93-84E5 | ||
Horse power | 88hp | ||
Emission | Euro V | ||
Displacement | 2540ml | ||
Tire | 7.00R16 steel wire tire | Transmission | 5 speed forward 1 reverse |
Steering device | Manual steering | Steering wheel | Left hand drive |
Remark: Other types of chassis as optional | ISUZU, Howo, Shacman, JAC | ||
Garbage Container Parameters | |||
Container material | Carbon steel | Container volume | 4-5m3 |
Side wall | 2.5mm | Bottom plate | 3mm |
Standard Configuration | |||
Chassis,sub frame,van body with rear door and top cover,scraper,hydraulic cylinder for unloading,garbage bins lifting system. | |||
