Small Van Truck 4X2 89HP diesel Euro III Factory Custom Sale

Parameter Category	Detailed Data
Basic Vehicle Information
Announcement Model	BJ5036XXY-D3
Vehicle Type	Box Van Truck
Drive Configuration	4×2 (2 front steering wheels + 2 rear driving wheels)
Wheelbase	3070 mm
Cargo Box Length Class	2.8 m
Engine Model	Wuling Liuji LJ469Q-1AE9
Transmission Model	Qingshan MR513B
Rear Axle Ratio	5.286
Overall Vehicle Length	4.945 m
Overall Vehicle Width	1.735 m
Overall Vehicle Height	2.42 m
Front Track Width	1338 mm
Rear Track Width	1375 mm
Curb Weight	1.32 tons (1320 kg)
Rated Payload Capacity	1.095 tons (1095 kg)
Gross Vehicle Weight (GVW)	2.545 tons (2545 kg)
Maximum Speed	115 km/h
Place of Origin	Suizhou, Hubei (China)
Tonnage Class	Micro-Card
Approach Angle	39°
Departure Angle	23°
Front Overhang/Rear Overhang	0.605 m / 1.27 m
License Plate Type	Blue License Plate (Compliant with China’s light-duty vehicle license standards)
Energy Type	Gasoline
Engine Parameters
Engine Brand	Wuling Liuji
Engine Model	Wuling Liuji LJ469Q-1AE9
Engine Series	Liuji Gasoline 1.3L
Number of Cylinders	4 Cylinders
Fuel Type	Gasoline
Cylinder Arrangement	In-line
Displacement	1.249 L
Emission Standard	Beijing V Emission (Beijing local fifth-stage emission standard)
Maximum Output Power	64 kW
Maximum Horsepower	87 HP
Maximum Torque	118 N·m
Maximum Torque Speed	6000 rpm
Rated Engine Speed	4000 rpm
Transmission Parameters
Transmission Model	Qingshan MR513B
Transmission Brand	Qingshan
Shifting Mode	Manual
Number of Forward Gears	5 Gears
Number of Reverse Gears	1 Gear
Cargo Box Parameters
Cargo Box Type	Box-type (Enclosed van structure for cargo protection)
Cargo Box Length	2.8 m
Cargo Box Width	1.56 m
Cargo Box Height	1.57 m
Internal Cargo Box Width	1.559999942779 m
